Code 213231
----------------------------------------------------------------------------------
Eléments 1
----------------------------------------------------------------------------------
Bande UHF
----------------------------------------------------------------------------------
Canaux E21-E48
----------------------------------------------------------------------------------
Largeur de bande MHz 470-694
----------------------------------------------------------------------------------
Gain dBi 47
----------------------------------------------------------------------------------
AGC dBµV 65-80
----------------------------------------------------------------------------------
Niveau de sortie dBµV 98
----------------------------------------------------------------------------------
Tension d'alimentation V 12-24
----------------------------------------------------------------------------------
Consommation mA 45 @12V
----------------------------------------------------------------------------------
Rapport avant/arrière dB 32
----------------------------------------------------------------------------------
Affaiblissement de réflexion dB -15
----------------------------------------------------------------------------------
Largeur du faisceau (-3dB) ° ±22
----------------------------------------------------------------------------------
Résistance au vent 120Km/h
----------------------------------------------------------------------------------
729N/m²
----------------------------------------------------------------------------------
Kg (N) 19 (186.3)
----------------------------------------------------------------------------------
Connecteur F
----------------------------------------------------------------------------------
Impédance Ohm 75
----------------------------------------------------------------------------------
Diamètre maximum fixation au mât mm 60
----------------------------------------------------------------------------------
Dimensions cm 92 x 82 x 62
----------------------------------------------------------------------------------
Accessoires
----------------------------------------------------------------------------------
Polarisation horizontale Y compris
----------------------------------------------------------------------------------
Réglage vertical en pol. horizontale Y compris
----------------------------------------------------------------------------------
Polarisation verticale Y compris
----------------------------------------------------------------------------------
Réglage vertical en pol. verticale Y compris
----------------------------------------------------------------------------------
Support auxiliaire N.P.
----------------------------------------------------------------------------------
Dimensions et conditionnement
----------------------------------------------------------------------------------
Conditionnement Individuel dans un carton
----------------------------------------------------------------------------------
Pièces 6
----------------------------------------------------------------------------------
Code EAN 8016978101061
----------------------------------------------------------------------------------
Code EAN 8016978101825
----------------------------------------------------------------------------------
Dimensions de l'emballage mm 1020 x 750 x 470
----------------------------------------------------------------------------------
Poids carton Kg 21.4
----------------------------------------------------------------------------------
Poids unitaire Kg 2.30
----------------------------------------------------------------------------------
Poids total conditionnement multiple Kg 18 |
