Eléments n° 16+16
----------------------------------------------------------------------------------
Bande 3+DAB / UHF
----------------------------------------------------------------------------------
Canaux E5-E12 + DAB / E21-E48
----------------------------------------------------------------------------------
Largeur de bande MHz 174-240 / 470-694
----------------------------------------------------------------------------------
Gain dBi 9 / 11
----------------------------------------------------------------------------------
Rapport avant/arrière dB 24 / 32
----------------------------------------------------------------------------------
Affaiblissement de réflexion dB -13 / -13
----------------------------------------------------------------------------------
Largeur du faisceau (-3dB) ° ±34 / ±31
----------------------------------------------------------------------------------
Résistance au vent 120Km/h 729N/m² Kg (N) 3.9 (38.2)
----------------------------------------------------------------------------------
Connecteur Borne
----------------------------------------------------------------------------------
Impédance Ohm 75
----------------------------------------------------------------------------------
Diamètre maximum fixation au mât mm 60
----------------------------------------------------------------------------------
Dimensions cm 115 x 86
----------------------------------------------------------------------------------
Accessoires
----------------------------------------------------------------------------------
Polarisation horizontale Inclus
----------------------------------------------------------------------------------
Réglage vertical en pol. horizontale - PV10 (210011)
----------------------------------------------------------------------------------
Polarisation verticale Inclus
----------------------------------------------------------------------------------
Réglage vertical en pol. verticale - PV10 (210011)
----------------------------------------------------------------------------------
Support auxiliaire N.P.
----------------------------------------------------------------------------------
Dimensions et conditionnement
----------------------------------------------------------------------------------
Pièces 20
----------------------------------------------------------------------------------
Dimensions carton mm - LxWxH 1100 x 1100 x 420
----------------------------------------------------------------------------------
Poids carton Kg 16.8
----------------------------------------------------------------------------------
Poids unitaire Kg 1.04
----------------------------------------------------------------------------------
Poids total conditionnement multiple Kg 21.3 |
