Code 223717
----------------------------------------------------------------------------------
Nombre d'entrées 2
----------------------------------------------------------------------------------
Entrées FM+III+DAB, UHF
----------------------------------------------------------------------------------
Fréquence FM MHz 88 - 108
----------------------------------------------------------------------------------
Fréquence DAB MHz 174 - 240
----------------------------------------------------------------------------------
Fréquence MHz 470 - 694
----------------------------------------------------------------------------------
Gain dB FM+III+DAB: 22; UHF: 28
----------------------------------------------------------------------------------
Réglage du gain dB FM+III+DAB: 15; UHF: 15
----------------------------------------------------------------------------------
Facteur de bruit typique dB
----------------------------------------------------------------------------------
III+DAB: 5;
----------------------------------------------------------------------------------
UHF: 4
----------------------------------------------------------------------------------
Nombre de sorties 1
----------------------------------------------------------------------------------
Niveau de sortie dBµV
----------------------------------------------------------------------------------
III+DAB: 112;
----------------------------------------------------------------------------------
UHF: 116
----------------------------------------------------------------------------------
Connecteurs F femelle
----------------------------------------------------------------------------------
Clipper No
----------------------------------------------------------------------------------
Filtre 5G
----------------------------------------------------------------------------------
Caractéristiques générales
----------------------------------------------------------------------------------
Tension d'alimentation V 24
----------------------------------------------------------------------------------
Consommation mA
----------------------------------------------------------------------------------
85 @24V
----------------------------------------------------------------------------------
Impédance Ohm 75
----------------------------------------------------------------------------------
Température de fonctionnement °C De -10 à +55
----------------------------------------------------------------------------------
Protection IP43
----------------------------------------------------------------------------------
Conformité EN50083-2: 2006-06
----------------------------------------------------------------------------------
Dimensions et conditionnement
----------------------------------------------------------------------------------
Pièces 1
----------------------------------------------------------------------------------
Code EAN 8016978101641
----------------------------------------------------------------------------------
Dimensions de l'emballage mm 128 x 111 x 111
----------------------------------------------------------------------------------
Dimensions du produit mm 120 x 50 x 105
----------------------------------------------------------------------------------
Poids carton Kg 0.540
----------------------------------------------------------------------------------
Poids Kg 0.500 |
