Input no. 3
----------------------------------------------------------------------------------
Inputs FM+III+DAB, UHF, UHF
----------------------------------------------------------------------------------
DAB, III Frequency MHz 174 - 240
----------------------------------------------------------------------------------
Frequency MHz 470 - 790
----------------------------------------------------------------------------------
Gain dB FM+III+DAB: 26; UHF: 28; UHF: 28
----------------------------------------------------------------------------------
Gain adjustment dB FM+III+DAB: 15; UHF: 15; UHF: 15
----------------------------------------------------------------------------------
Optical noise figure dB III+DAB: 5; UHF: 7
----------------------------------------------------------------------------------
Outputs number 2
----------------------------------------------------------------------------------
Output level dBµV III+DAB: 112; UHF: 116
----------------------------------------------------------------------------------
Connectors F female
----------------------------------------------------------------------------------
Specifications
----------------------------------------------------------------------------------
Power supply voltage V 12
----------------------------------------------------------------------------------
Absorption mA 140
----------------------------------------------------------------------------------
Impedence Ohm 75
----------------------------------------------------------------------------------
Operating temperature °C -10 to +55
----------------------------------------------------------------------------------
Protection IP43
----------------------------------------------------------------------------------
Conformity EN50083-2: 2006-06
----------------------------------------------------------------------------------
Dimensions and packaging
----------------------------------------------------------------------------------
Pieces : 1
----------------------------------------------------------------------------------
EAN code 8016978100859
----------------------------------------------------------------------------------
Packaging dimensions mm 124 x 57 x 118
----------------------------------------------------------------------------------
Product dimensions mm 120 x 50 x 105
----------------------------------------------------------------------------------
Packaging weight Kg 0.29
----------------------------------------------------------------------------------
Net Weight Kg 0.234
----------------------------------------------------------------------------------
Weight Kg 0.251 |
